Outer diameter D(mm) | 80, 100(mm) |
---|---|
Grit | 500, 1000, 2000, Tsuya |
Applicable materials | Marble |
Size (mm) | 120x80 (mm) |
---|---|
Grit available | 500, 1000, 2000, Tsuya |
Applicable materials | Marble |
Applicable machine | Sanders |
Metal type | |
---|---|
Outer Diameter D(mm) | 75 (mm) |
Mouting attachment | M16, 5/8, One-touch joint |
Grit available | 60, 100, 200, 400 |
Resin type | |
---|---|
Outer Diameter D(mm) | 50, 75 (mm) |
Mouting attachment | 50(mm)-M16 75(mm)-M16, One-touch joint |
Grit | 200, 400, 800, 1500, 3000 |
Buff and Tsuya type | |
---|---|
Outer Diameter D(mm) | 50, 75 (mm) |
Mouting attachment | 50(mm)-M16 75(mm)-M16, One-touch joint |
Grit | Buff(Black), Buff(Green), Buff(MB), Buff(NP), Tsuya(R) |
Metal type | |
---|---|
Outer Diameter D(mm) | 75 (mm) |
Grit | 40, 60, 80, 200 |
Form | Standard(Height 40mm) High ver(Height 52mm: for building products) |
Resin type | |
---|---|
Outer Diameter D(mm) | Resin diamond: 75(mm) Resin: 80(mm) |
Grit | Resin diamond: 300, 800, 1500 Resin: 200, 400, 800, F, S |
Form |
Standard(Height 40mm) High ver(Height 52mm: for building products) |
Criteria for selecting Buff type | |
---|---|
Grit | Criteria |
Black | Black color or dark color granite |
MB(white) | White color or bright color granite |
NP | Marble, Tile |
R | Unlike Buff finishing surface, looks similar to abrasive finishing surface |
TYPE 1 | |||
---|---|---|---|
Outer diameter D(mm) |
Inner diameter C(mm) |
Base plate material | Grit |
150 | 25.4 | Bakelite |
500 1000 2000 Tsuya |
200 | |||
250 |
TYPE 2 | ||||
---|---|---|---|---|
Outer diameter D(mm) |
Inner diameter C(mm) |
Base plate material | Grit | Form |
100 | 25.4 | Bakelite |
500 1000 2000 Tsuya |
Groove type Quartering type with groove Quartering type without groove |
125 | ||||
150 | ||||
200 | ||||
80 | - | without base plate | - | |
100 | Non groove type Groove type |
|||
125 | ||||
150 |
TYPE 4 | ||||
---|---|---|---|---|
Outer diameter D(mm) |
Inner diameter C(mm) |
Base plate material | Grit | Form |
100 | 25.4 | Bakelite |
500 1000 2000 Tsuya |
Groove type Quartering type with groove Quartering type without groove |
125 | ||||
150 | ||||
200 | ||||
80 | - | without base plate | - | |
100 | Non groove type Groove type |
|||
125 | ||||
150 |
Outer diameter D(mm) |
Inner diameter C(mm) |
Base plate material | Number of Chips(N) | Grit | Hardness |
---|---|---|---|---|---|
100 | 25.4 | Cast metal | 5 | 50 80 200 400 |
(hard)A4>A5>A6(soft) |
125 | 6 | ||||
150 | |||||
175 | 9 | ||||
200 | 12 | ||||
250 | |||||
300 | 18 | ||||
325 |
Outer diameter D(mm) |
Inner diameter C(mm) |
Base plate material | Number of Chips(N) | Grit | Hardness |
---|---|---|---|---|---|
100 | 25.4 | Cast metal | 5 | 50 80 200 400 |
(hard)A4>A5>A6(soft) |
125 | 6 | ||||
150 | |||||
175 | 9 | ||||
200 | 12 | ||||
250 |
Outer diameter D(mm) |
Inner diameter C(mm) |
Base plate material | Number of Chips(N) | Type | Grit | Hardness |
---|---|---|---|---|---|---|
200 | 25.4 | Aluminum | 6 | normal/slim | 60 80 200 400 |
D40(hard) D50 D60(soft) |
250 | normal | |||||
200 | without base plate | normal/slim | ||||
250 | normal |
Outer diameter D(mm) |
Inner diameter C(mm) |
Base plate material | Number of Chips(N) | Grit | Hardness |
---|---|---|---|---|---|
150 | 25.4 | Aluminum |
6 | 60 80 200 400 |
R50 |
200 | 9 | 50 60 80 200 400 |
R40 R50 R60 |
||
250 | |||||
150 | - | without base plate | 6 | 60 80 200 400 |
R50 |
200 | 9 | 50 60 80 200 400 |
R40 R50 R60 |
||
250 |
Resin type | |
---|---|
Outer Diameter D(mm) | Resin diamond: 75(mm) Resin: 80(mm) |
Grit | Resin diamond: 300, 800, 1500 Resin: 200, 400, 800, F, S |
Form |
Standard(Height 40mm) High ver(Height 52mm: for building products) |
Buff and Tsuya type | |
---|---|
Outer Diameter D(mm) | 75(mm) |
Grit | Black, MB, NP(Marble, Tile), R |
Form |
Standard(Height 40mm) High ver(Height 52mm: for building products) |
Criteria for selecting Buff type | |
---|---|
Grit | Criteria |
Black | Black color or dark color granite |
MB(white) | White color or bright color granite |
NP | Marble, Tile |
R | Unlike Buff finishing surface, looks similar to abrasive finishing surface |
Outer diameter D(mm) |
Inner diameter C(mm) |
Base plate material | Grit | form |
---|---|---|---|---|
125 | 25.4 | Aluminum | 50 100 200 400 |
eccentric circle(L) concentric circle |
OD(mm) | Inner diameter C(mm) |
Base plate material | Grit | Hardness |
---|---|---|---|---|
100 | 25.4 | Aluminum Bakelite |
200 400 500 800 1000 1500 2000 3000 |
M4A(hard) M5A M6A(soft) |
125 | ||||
150 | ||||
175 | ||||
200 | ||||
250 | ||||
300 | Bakelite |
Outer diameter D(mm) |
Inner diameter C(mm) |
Base plate material | Grit |
---|---|---|---|
150 | 25.4 | Aluminum |
400 500 800 1000 Gloss High-Gloss |
200 | |||
250 |
OD(mm) | Inner diameter C(mm) |
Base plate material | Grit | form |
---|---|---|---|---|
100 | 25.4 | Bakelite | 200 400 800 1500 3000 |
eccentric circle(L) concentric circle |
125 | ||||
150 |
Outer diameter D(mm) | 125, 150 |
---|---|
Grit | 200, 500, 1000, 2000, 3000 |
Backing plate material | Aluminum, Bakelite, EC |
Outer diameter D(mm) |
125, 150 |
---|---|
Type | S, MB, NP, R |
Base material | EC |
Outer diameter D(mm) |
125, 150 |
---|---|
Type | S, MB, NP, R |
Base material | EC |
